2026 Columbia Stockchaser 48 Volt

2026 Columbia Stockchaser 48 Volt

Location:Tampa, FL

Description

Columbia’s Stockchaser is the way to move heavy loads in tight spaces. With a deck capacity of up to 1,200 lbs., you’ll be hard-pressed to need to move more cargo than this compact performer can transport with ease. An optional 48V package increases the Stockchaser’s towing capacity to 6,000 lbs., making it the perfect vehicle to transport heavy loads in narrow spaces. The adjustable backrest and stand-up operation provide a safe and comfortable position for the driver, and the Stockchaser’s tubular steel chassis and steel body panels make it as rugged as it is maneuverable! With its standard dual-tire front fork, Columbia’s Stockchaser is the most stable, narrow aisle burden carrier available on the market today. Options: Optional 4 or 6 Step Ladder; Transport Package; Adjustable Back Seat (Standard)

Specifications

ManufacturerColumbia
ModelStockchaser 48 Volt
Year2026
ConditionNew
Stock Number9680134
SeriesStockchaser
Height48 in
Width29.5 in; Transport Pkg.: 52.5 in
Length85.7 in; Transport Pkg.: 87.2 in
Wheel Base46 in; Transport Pkg.: 44 in
Bed/Deck Dimensions43 in L x 29.5 in W
Step Height6 in / 15.24 cm
Load Bed Height24 in / 60.96 cm
Ground Clearance3.5 in / 8.89 cm
Max Speed Forward9 mph
Turning RadiusIntersecting aisle - 55 in / 139.70 cm
RangeUp to 40 miles / 64.37 km
Vehicle Weight990 lb / 449.06 kg
Rated CapacityUp to 1,000 lb / 453.59 kg
Towing CapacityUp to 6,000 lb / 2721.55 kg
Motor3.3 kW AC
Horsepower4.4 hp / 3.3 kW AC
BatteriesEight, 6-volt, 232 amp hour, 122 minute, deep cycle
ChargerBuilt-in, micro-processor controlled, fully sealed, global, 110 - 240 VAC, 50/60 HZ
Controller TypeProgrammable, solid state, reduced speed reverse with diagnostic LED & calibrator interface
Controller Rating400 amp AC
Motor Braking ModeRegenerative and pedal proportional braking with top speed limiting
Directional ControlFully electronic direction switching with console mounted selector switch
Drive Unit/DifferentialAutomotive style, helical gears in oil bath, direct to motor, 16.99:1 final drive ratio
Passenger CapacityOne (Optional Transport Express Package: Up to seven)
SeatingStand-up operation; adjustable padded back rest
Body14-gauge powder coated structural steel smooth plate body
LightingOptional - LED head, tail & brake light with tail light guard
AccessoriesHorn; battery discharge indicator; reverse warning alarm; composite deck board with high-density polyethylene overlay
FrameHeavy-duty welded steel chassis with 14-gauge structural steel smooth body
SteeringDual front fork, direct link mechanical steering wheel
BrakesDual mechanical rear drum, automatically engaged upon dismount
SuspensionRigidly mounted
Tires4.80 in X 8 in / 12.19 cm x 20.32 cm, pneumatic, 4-ply rated, load range B
